ITS/Enforcement Portable scale

Home » ITS/EnforcementScales » Portable Weigh-In-Motion » LS630-WIM™ Portable Low-Speed Weigh-In-Motion Scale
for Enforcement

LS630-WIM™ Portable Low-Speed Weigh-In-Motion Scale
for Enforcement

Click image to enlarge

RFX Wireless Weighing

Price Each: Call for Price

Quantity:

Features:

Capacity up to 40,000 kg Per Axle (150% Overload Protection)
Dynamic Accuracy of 2% to 3%
Certified NTEP Static / OIML R134 WIM
Wireless & Wired Indicator Options
AC/DC Operation (Alkaline or Rechargeable Batteries)

Portable LS-WIM Scale for Enforcement Description

Intercomp LS630-WIM™ Portable Weigh-In-Motion Scales provide authorities the ability to bring screening and/or direct enforcement capabilities to areas not served by permanent weigh stations. Configurations consist of just two Portable Low-Speed Weigh-In-Motion Scales, four roll up ramps/levelers and the CPU or PC. This provides authorities with a fast, efficient and cost effective solution for portable truck scales to protect roadways and concentrate enforcement almost anywhere you need it.

At Intercomp, we manufacture LS630-WIM™ Scale Systems with an OIML R134 certified dynamic accuracy of 2 to 3% at low speed. LS630-WIM™ scales are NTEP certified in static mode with an accuracy of ± 0.5%. The scales collect axle weights, group weights, gross vehicle weight, and axle spacing data for a full vehicle weight profile. If you have specific questions regarding our Portable Low-Speed Weigh-In-Motion Scale options, get in touch with our sales team and we will gladly answer any questions you have regarding your specific requirements.

LS630-WIM™ Portable Low-Speed Weigh-In-Motion Scale Advantages

LS630-WIM™ Scale Systems combine the timesaving qualities of Weigh-In-Motion with the convenience of portable scales. The RFX® Wireless communication between the portable WIM scales and optional indicators allows for quick set up and easy operation. Scales are operated via the TS30™ Touchscreen CPU and printer, the PT20™ WIM CPU and printer, or with a PC using IntercompWIM™ software. Wireless communication is standard on both devices while cables can be used for back up purposes. Additional LS630-WIM™ Scale System benefits include:

Scales Switch between Static and Weigh-In-Motion Mode at the Push of a Button
Capacity up to 40,000 kg Per Axle (150% Overload Protection)
Certified NTEP Static / OIML R134 WIM
AC/DC Operation (Alkaline or Rechargeable Batteries)
Used in Enforcement for Screening or Issuing Citations

LS630-WIM™ Enforcement Applications

Portable WIM scales allow for temporary sites to be set up wherever enforcement efforts are needed, and increase efficiency and throughput of screening vehicles for weight violations. Due to its portability, certified accuracy, and versatility of operation in WIM and static modes, the LS630-WIM™ Portable Weigh-In-Motion scale system is used worldwide for vehicle screening and enforcement applications. The following applications reflect the use potential of Intercomp’s Portable Weigh-In-Motion Scales.

LS630-WIM™ Portable Low-Speed Weigh-In-Motion Scales for Law Enforcement

Transportation departments, ministries of transportation, and enforcement officials throughout the globe rely on Intercomp LS630-WIM™ Portable Weigh-In-Motion Scales for law enforcement purposes. Low-Speed Weigh-In-Motion Scales meet the requirements for accuracy of systems employed in enforcement WIM applications. They are Class lIII NTEP Certified for direct enforcement in static weighing mode and OIML R134 Certified in Weigh-In-Motion mode.

WIM Scales for Screening Enforcement

portable wim scales MN State Patrol Portable Screening

Novel In-Ground Use of Portable Scales

Resource Library

Publications We have many other published resources including a variety of literature, technical articles, application notes, videos, vehicle scale basics guides, and certification notes.

Please VISIT OUR RESOURCE LIBRARY to learn more about ITS/Enforcement Scale applications, examples, case studies and specifications.

Portable Low-Speed Weigh-In-Motion Scale Indicators

We Also Recommend

Certifications

View our OIML R-134 Certificate here.
View our NTEP Certificate here.

For a complete list of all Certificates held by Intercomp, visit the Certifications section in our Resource Library.

Portable Weigh-In-Motion Scale Overview

Contact Intercomp for LS630-WIM™ Portable Low-Speed Weigh-In-Motion Scales Today

At Intercomp, we manufacture state-of-the-art Portable Weigh-In-Motion Scales for a wide range of industries throughout the world. Our Portable LS-WIM™ Scales can provide quick and accurate weight measurements at low speeds, and can be operated in static mode for vehicle axle weights where required.

Get in touch with our sales team for more information or further pricing details regarding our accurate and reliable Portable LS-WIM™ options. Intercomp is the industry’s most trusted supplier of Portable Low-Speed Weigh-In-Motion Scales.
